41-40 |
41-63 |
41-80 |
41-100 |
41-100A |
41-160 |
||||
|
Capacity |
kN |
400 |
630 |
800 |
1000 |
1000 |
1600 |
|||
|
Return Force |
kN |
80 |
69 |
115 |
135 |
135 |
210 |
|||
|
Max. Hydraulic Pressure |
mm |
25 |
25 |
25.5 |
25 |
25 |
26 |
|||
|
Slide Stroke |
mm |
400 |
500 |
500 |
500 |
500 |
560 |
|||
|
Throat Depth |
kN |
280 |
320 |
320 |
380 |
500 |
400 |
|||
|
Shut Height |
Straightening |
mm |
600 |
700 |
700 |
700 |
750 |
900 |
||
|
Pressing |
mm |
800 |
1000 |
1000 |
1000 |
1100 |
1120 |
|||
|
Slide Speed |
Idle Stroke |
mm/s |
110 |
130 |
70 |
75 |
75 |
75 |
||
|
Pressing |
mm/s |
9-22 |
6-14 |
8-18 |
7-15 |
7-15 |
7-15 |
|||
|
Return |
mm/s |
110 |
125 |
100 |
90 |
90 |
110 |
|||
|
Bolster |
LR |
Straightening |
mm |
1100 |
1200 |
1200 |
1400 |
2000 |
1600 |
|
|
Pressing |
mm |
620 |
720 |
720 |
850 |
1000 |
1000 |
|||
|
FB |
mm |
520 |
600 |
600 |
720 |
800 |
720 |
|||
|
Slide |
LR |
mm |
560 |
620 |
700 |
700 |
700 |
700 |
||
|
FB |
mm |
420 |
460 |
500 |
500 |
500 |
500 |
|||
|
Bolster Height Above Floor |
mm |
720 |
750 |
780 |
820 |
820 |
600 |
|||
|
Bolster Opening |
mm |
φ120 |
φ150 |
φ180 |
φ200 |
φ200 |
/ |
|||
|
Outline Size |
LR |
Straightening |
mm |
1250 |
1280 |
1350 |
1400 |
2000 |
1600 |
|
|
Pressing |
mm |
1250 |
1280 |
1350 |
1400 |
1400 |
1600 |
|||
|
FB |
mm |
1300 |
1450 |
1550 |
1900 |
2250 |
2300 |
|||
|
Above Floor |
Straightening |
mm |
2600 |
2750 |
2860 |
2920 |
3020 |
3200 |
||
|
Pressing |
mm |
2800 |
3050 |
3160 |
3220 |
3370 |
3350 |
|||
|
Below Floor |
mm |
/ |
/ |
/ |
/ |
/ |
/ |
|||
|
Main Motor Power |
kW |
5.5 |
5.5 |
7.5 |
7.5 |
7.5 |
15 |
|||
|
Weight |
Straightening |
kg |
2800 |
4200 |
5300 |
6400 |
7400 |
11000 |
||
|
Pressing |
kg |
3000 |
4500 |
5500 |
6800 |
7800 |
12000 |
|||
